How to Open a SketchUp Model in Revit

Importing SketchUp models into Revit is a common workflow in the architecture, engineering, and construction (AEC) industries. Since SketchUp and Revit use different design and modeling methods, their file formats are not fully compatible, meaning that transferring a SketchUp model into Revit requires specific steps and techniques. This article explores how to import SketchUp models into Revit, offering tips and optimization methods to help you increase workflow efficiency and design accuracy.

Why Import a SketchUp Model into Revit?

SketchUp, as a quick modeling tool, is ideal for creating initial design sketches, conceptual models, 3D visualizations, and renderings. Its simple and user-friendly interface allows users to rapidly build basic architectural or landscape models. On the other hand, Revit is a powerful Building Information Modeling (BIM) software used extensively for architectural, structural, and MEP (mechanical, electrical, plumbing) design. Revit facilitates detailed design analysis, engineering drawings, and construction document generation. Therefore, many designers and engineers choose to import SketchUp models into Revit in order to:

· Increase efficiency: By quickly building prototypes in SketchUp and importing them into Revit, significant time can be saved.

· Achieve BIM integration: Importing SketchUp models into Revit allows design teams to work more effectively in a BIM environment.

· Refine design details: Revit provides tools to fine-tune and finalize SketchUp models, ensuring compliance with building codes, structural safety, and other requirements.

· Generate high-quality construction drawings: Revit’s powerful documentation tools help convert designs into detailed construction drawings and technical documentation.

Common Methods for Importing SketchUp Models into Revit

Due to the incompatibility between SketchUp and Revit, you’ll need to take an indirect approach to transfer files from SketchUp to Revit. Below are several common methods for importing models, each with its own pros and cons. Choosing the best method for your project is key to a smooth import process.

1. Import Using FBX Format

FBX is a widely-used file format, particularly in 3D modeling and rendering, and it offers good compatibility between various 3D applications. SketchUp supports exporting models in FBX format, which Revit can also import, making it a practical method.

In SketchUp, you can choose the "Export" option and save the model in FBX format. FBX files preserve model geometry and can retain some basic materials and texture information. When importing the FBX file into Revit, it is treated as a reference file, allowing further editing and optimization within Revit.

Advantages:

· Supports data exchange between multiple 3D software programs and has good compatibility.

· Retains basic material and texture information.

Disadvantages:

· Complex models and materials may be lost or distorted, especially with complex curves or detailed elements.

· Does not preserve Revit's BIM data structure, only the geometry data.

2. Import Using DWG Format

DWG is AutoCAD’s native file format and is one of the most commonly used formats in the architectural design field. By exporting SketchUp models as DWG files and importing them into Revit, you can exchange basic geometric data. This method is particularly useful for simple 2D or 3D graphics.

In SketchUp, select the "File" menu and choose "Export" to save the model in DWG format. Be sure to select the correct coordinate system and scale during export to prevent issues with positioning or scaling when importing into Revit. Once imported, Revit treats the DWG file as a background layer for further modeling.

Advantages:

· DWG is one of the most widely used formats in architecture, and Revit provides excellent support for it.

· Quickly imports basic geometric models from SketchUp into Revit.

Disadvantages:

· Only geometry and 2D drawings can be imported; more complex materials and textures are not preserved.

· The layer structure or modeling history from SketchUp is not retained in Revit.

3. Use Rhino and Revit Plugin for Conversion

Rhino is a powerful 3D modeling software, particularly suitable for surface modeling and creating complex geometries. You can create models in SketchUp and then export them to a format that Rhino can recognize (e.g., .OBJ, .3DS), and then use Rhino to convert the model into a format supported by Revit.

There is good interoperability between Revit and Rhino, especially with the use of Rhino’s Revit plugin, Revit RIH, which allows you to import Rhino models into Revit. This method is ideal for transferring complex 3D models from SketchUp into Revit.

Advantages:

· Better handles complex surfaces and details.

· Converts model data into a format that Revit can process more accurately.

Disadvantages:

· Requires additional software (Rhino) and plugins, adding complexity to the process.

· Complex models may need further optimization to avoid performance issues when importing into Revit.

4. Import Using IFC Format

IFC (Industry Foundation Classes) is an open standard in the AEC industry and is widely used for BIM data exchange. IFC format can store rich architectural information and is ideal for sharing building data across disciplines such as architecture, structure, and MEP. By exporting a SketchUp model to IFC format and importing it into Revit, you can facilitate collaboration and ensure the model’s data structure remains consistent.

SketchUp models can be exported to IFC format using the IFC Exporter plugin, and once exported, the file can be imported into Revit using the "Import IFC" feature. The IFC file will be treated as part of the building information model in Revit, retaining more building details and information.

Advantages:

· Retains more architectural information and is suitable for BIM workflows.

· Supports data exchange across architecture, structure, MEP, and other disciplines.

Disadvantages:

· Requires the installation of a plugin and may not be suitable for simple projects.

· Exported IFC files may contain unnecessary information, requiring cleanup and optimization during import.

5. Use Revit Plugins or Third-Party Tools

With technological advancements, several third-party plugins have emerged that simplify the file conversion process between SketchUp and Revit. Examples include the SimLab SketchUp to Revit plugin and the Kubity plugin, which enable seamless transfers from SketchUp to Revit.

These plugins typically address common format compatibility issues, ensuring that SketchUp models are imported into Revit with minimal loss of data, and often support optimization features.

Advantages:

· Simplifies the import process, making it ideal for busy designers and engineers.

· Offers good compatibility and automatic fixes for common issues.

Disadvantages:

· Requires installation of additional plugins, which may add to the software’s complexity.

· Some plugins may require a purchase or subscription.

How to Optimize Imported Models

After importing a SketchUp model into Revit, you may encounter some format compatibility issues, especially with textures, materials, and scale. To ensure the model displays and functions correctly in Revit, some optimization is usually necessary:

· Check Scale and Position: The imported model may need to be adjusted to the correct position within the Revit project, especially when using DWG or FBX formats. Make sure the model is correctly placed in space.

· Fix Materials and Textures: Revit’s material system differs significantly from SketchUp’s, so you may need to manually adjust materials, texture mappings, or even reapply textures after import.

· Adjust Geometry: Since SketchUp and Revit handle geometry differently, you may need to fix or modify imported geometry to ensure it meets Revit’s requirements and avoid unnecessary errors.

Importing SketchUp models into Revit is a common design workflow that helps designers bring their quickly built models into a BIM environment for further analysis and refinement. Whether using FBX, DWG, IFC, or through Rhino plugins, each method serves a specific purpose. After import, further optimization is necessary to ensure the model performs at its best in Revit.
